Electric Mining Truck with Long Drive Range Large Battery Capacity and Dual Motor Drive

Electric Mining Truck with Long Drive Range Large Battery Capacity and Dual Motor Drive

Long Drive Range Electric Mining Truck

Large Battery Capacity Electric Mining Truck

Dual Motor Drive Electric Mining Truck

Herkunftsort:

Chengdu, China

Markenname:

ZEVAUTO

Zertifizierung:

ISO, CE

Modellnummer:

XZ110EV

Kontakt mit uns
Bitte um ein Angebot
Produkt-Details
Produktname:
Elektrischer Bergbau-LKW
Typ:
Null Emission
FULE -Typ:
Elektrisch
Abmessungen (mm):
9950*3750*4200
Radstand ((mm):
4500+1750 mm
Übertragung:
FAST 4-Gang-AMT-Ganggetriebe für Bergbaufahrzeuge.6.508-1.000
Maximale Geschwindigkeit:
40 km/h
Suspension:
Vordere oleopneumatische Federfeder + Hinterblätterfeder + verstärkte Ausgleichsfederung
Lenkung:
Vollhydraulisches Lenken + Notlenken
Antriebsmotor:
Auftriebsmotor mit zwei Motoren (Lego)
Suspensionssystem:
Vordere hydropneumatische Federfederung/hintere Federfederfederung
Bremssystem:
Elektrische Bremse + Trommelbremse, Wirbelstromverzögerung (optional)
Nennleistung des Motors/Spitzenleistung (kW):
Radnabe: 495/800; Lego: 500/800
Reifen:
16.00R25 Dreistern-Bewertung (Techking). Andere Reifenmarken sind verfügbar.
Container Volumen (m³):
42 (Flachbeladung)/45 (Stauvolumen)
Hervorheben:

Long Drive Range Electric Mining Truck

,

Large Battery Capacity Electric Mining Truck

,

Dual Motor Drive Electric Mining Truck

Zahlungs-u. Verschiffen-Ausdrücke
Min Bestellmenge
1
Verpackung Informationen
Nacktpackung
Lieferzeit
25-40 Arbeitstage
Zahlungsbedingungen
T/T, L/C
Versorgungsmaterial-Fähigkeit
25000 Einheiten/pro Jahr
Produktbeschreibung
Electric Mining Truck with Full Hydraulic Steering

Zero-emission electric mining truck featuring long drive range and large 528kWh battery capacity, designed for efficient and environmentally friendly mining operations.

Product Specifications
Attribute Value
Product name Electric Mining Truck
Type Zero Emission
Fuel type Electric
Dimensions (mm) 9950*3750*4200
Wheelbase (mm) 4500+1750
Transmission FAST 4-speed AMT mining truck transmission. Gear: 6.508-1.000
Max speed 40km/h
Suspension Front oleo-pneumatic spring suspension + Rear leaf spring + Reinforced balanced suspension
Steering Full hydraulic steering + emergency steering
Drive motor Disc hub dual-motor/Lego (optional)
Brake system Electric brake + drum brake, eddy current retarder (optional)
Motor rated/peak power (kW) Disk hub: 495/800; Lego: 500/800
Tire 16.00R25 three-star rating (Techking). Other brands available.
Container volume (m³) 42 (flat loading)/45 (stowage loading)
Model XZ95EV Technical Parameters
Vehicle dimension (mm) 9400*3750*4000
Minimum ground clearance 400mm
Battery Capacity 528kWh, LiFePo4
Power motor Dual motor 900K: 495kW/2000rpm/2380Nm
Electric Mining Truck with Long Drive Range Large Battery Capacity and Dual Motor Drive 0
Key Advantages
  • Zero emission environmentally friendly operation
  • 60-70% lower energy costs compared to diesel
  • Reduced maintenance requirements
  • Lower center of gravity improves stability on slopes
  • Meets EPA Tier 5/EU Stage V emissions standards
  • Safe and reliable operation with strong power output
  • High operation efficiency and comfortable driving experience
Customization Options

Electric mining truck configurations available to meet specific operational requirements.

About ZEV

Headquartered in Chengdu, Sichuan province, China, ZEV is a group company specializing in the development, production, sales and market application of buses and coaches. Since its foundation in 2006, ZEV's culture of continuous innovation has made it a leading manufacturer in China.

With two production plants and annual capacity of 25,000 units, ZEV offers a 5m-18m product lineup of battery electric buses and coaches. In 2022, ZEV was awarded 825 units of 12m full electric city buses for Chengdu Transport Cooperation, with 400 units serving during the 31st FISU World University Games.
